8 Ton Low-Temperature Resistant Knuckle Boom Offshore Crane
Introducing OUCO's cutting-edge 8T16M knuckle boom crane, specially engineered for deployment on Russian scientific research vessels operating in challenging environments such as the northern temperate and frigid zones.
The prolonged, harsh winters in these regions demand top-notch quality from offshore cranes, and OUCO delivers with its extensive experience in developing low-temperature resistant deck cranes. Our latest offering, the two 8-ton 16-meter folding arm offshore cranes, excels in extreme cold down to minus 40 degrees Celsius.
Crafted with a low-temperature resistance and sealing design, the hydraulic system and electronic components ensure reliable operation even in the harshest conditions. Certified by the Russian Classification Society RS, these cranes boast wireless remote control functionality for enhanced convenience and efficiency.
With a robust CX-level 300mm thick three-layer coating, providing surface protection for over 15 years, our crane is built to withstand the test of time.
At OUCO, we prioritize customer satisfaction, offering customization options to tailor ship cranes to different structural forms, arm lengths, moments, and sea conditions. We extend a warm invitation to customers from around the globe to visit OUCO for on-site factory inspections, ensuring confidence in our exceptional products and services.
Technical Parameters
技术参数
TECHNICAL PARAMETERS |
| 1. | 安全工作负荷(SWL) | SEE LOAD CHART |
| 2. | 最大工作半径(MAX. WORKING RADIUS) | 16W |
| 3. | 最小工作半径(MIN. WORKING RADIUS) | 2.6M |
4.
5. | 起升速度(HOISTING SPEFD) | |
| 绞车(WINCH) | ~23m/min |
| 吊钩行程(HOOK TRAVEL) | 30m |
| 6. | 回转速度(SLEWING SPEFD) | 1.1r/min |
| 7. | 回转角度(SLEWING ANGLE) | 360° |
| 8. | 一变幅时间(FIRST LUFFING TIME) | ~90S |
| 9. | 二变幅时间(SECOND LUFFING TIME) | ~75s |
| 11. | 工作状态(WORKING CONDITION) | SEE LOAD CHART |
| 纵倾(TRIM) | ≤2° |
| 横倾(HEEL) | ≤5° |
| 12. | 电动机型号(ELEC-MUTOR POWER) | Y280S-4-H |
| 功率(POWER) | 75kW |
| 转速(SPEED) | 1480r/min |
| 电制(POWER RESOURCE) | AC380V/50HZ/3P |
| 防护等级(PROTECT CLASS) | IP68 |
| 绝缘等级(INSUKATE CLASS) | F |
| 工作制(WORKING TYPE) | S1 |
| 13. | 设计温度(design temprature) | -40*～+35* |
| 14. | Operation method | Manual or wireless remote control |
GA Drawing
Product Picture
FAQ
1. Q: Can this type work in hazardous environments?
A: Sure! We can customize it for you, acid-proof or explosion-proof, no problem with that.
2. Q: Can you provide the serious lifting tools?
A: Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, magnet or other specials as your requirement!
3. Q: How can we install the crane?
A: Our senior engineer can be on your side to do the installation guide service and training. Moreover, our best sales can visit your country.
4. Q: Safety device
A: Overload limiter, Limit Switch (lifting and traveling), Interlock protection device.
|
|
8 Ton Low-Temperature Resistant Knuckle Boom Offshore Crane Images
|
